Main Technical Indicators of Metal 3D Printing Powder

(Main Technical Indicators of Metal 3D Printing Powder)

As an emerging manufacturing technology, 3D printing has developed rapidly in
recent years. However, for the industrial metal 3D printing field, powder
consumables are still one of the important factors restricting the large-scale
application of this technology. At present, no industry standards or national
standards such as metal 3D printing material standards, process specifications,
and parts performance standards have been formulated. Generally, the evaluation
indicators for metal powder mainly include chemical composition, particle size
distribution, powder sphericity, fluidity, and bulk density. Among them,
chemical composition and particle size distribution are commonly used indicators
for evaluating the quality of metal powder in the field of metal 3D printing,
and sphericity, fluidity, and loose density can be used as reference indicators
for evaluating quality.

At present, the most widely used methods for detecting the chemical
composition of metals are chemical analysis and spectroscopy. Chemical analysis
is the use of chemical reactions to determine the composition of metals, which
can achieve qualitative and quantitative analysis of the chemical composition of
metals; spectral analysis is the use of various elements in metals that produce
their own unique characteristics under high temperature and high energy
excitation Spectroscopy is used to determine the chemical composition and
approximate content of metals, and is generally used for qualitative analysis of
the chemical composition of metals. The above two methods must use professional
testing equipment and be completed by the personnel of professional testing
institutions.

The particle size distribution of the metal powder can be analyzed by a laser
particle size analyzer. The particle size range of powders commonly used in
metal 3D printing is 15~53μm (fine powder) and 53~105μm (coarse powder). This
particle size range is divided according to metal printers with different energy
sources. Printers with lasers as energy sources have a fine focus spot and are
easier to melt fine powder. It is suitable to use 15~53μm powder as consumables
because it is within this particle size range. The powder has good fluidity and
is easy to dissolve. The powder replenishment method is to spread the powder
layer by layer; the printer with plasma beam as the energy source has a slightly
coarse focus spot, which is more suitable for melting coarse powder, suitable
for 53~105μm The powder is used as a consumable, and the powder replenishment
method is coaxial powder feeding.

The sphericity is the degree to which the metal powder particles are close to
the sphere, which is generally qualitatively analyzed by scanning electron
microscope (SEM). Generally speaking, the sphericity is good, and the fluidity
of the powder particles is also good. It is easier to spread and feed the powder
in metal 3D printing. Fluidity refers to the time required for a certain amount
of metal powder particles to flow through a measuring tool with a specified
aperture. The usual unit is s/50g, which can be measured by a Hall flow meter.
The smaller the value, the better the fluidity of the powder. Fluidity can also
be characterized by the angle of repose. The angle of repose refers to the
maximum angle measured in a gravitational field when the gravity and the
friction between the particles are balanced when the particles slide on the free
slope of the metal powder accumulation layer. . This is a simple method to test
the fluidity of metal powder. The smaller the angle of repose, the smaller the
friction and the better the fluidity, which is more conducive to powder
spreading and powder feeding.
