Powder Bed Electron Beam Molten Metal 3D Printing, Titanium Powder Can be Reused Many Times!

(Powder Bed Electron Beam Molten Metal 3D Printing, Titanium Powder Can be Reused Many Times!)

In a study recently published by a research group, using X-ray microcomputer
tomography (CT), the porosity produced by Ti6Al4V powder bed melting-electron
beam melting (PBF-EB) additive manufacturing was carried out a series of 30
times. Characterization of the build cycle (including approximately 480 hours of
cumulative build time). Studies have shown that additively manufactured powders
can be reused up to 30 times without a significant increase in porosity.

In the pursuit of the industrialization of metal additive manufacturing (AM),
powder reuse has become a core issue. In addition, porosity is a key issue for
the reliability of metal parts and the damage tolerance of metals. However, the
contribution of powder reuse to metal porosity has received little
attention.

The pores are derived from the pores of the gas atomized TC4 powder and the pores
caused by the incomplete fusion of the molten pool. Although the pore size
distribution decreases slightly with the repeated use of the powder, the overall
average volume porosity is 0.10±0.02%, and with the increase in repeated use,
the porosity does not change significantly.

In addition, the study also found that there is an inverse relationship
between the aperture and the sphericity, and the large aperture constitutes a
greater effective stress concentration. The largest pore density is located at
the transition between the contour line and the melt beam. For parts near the
surface of about 0.5-1.0mm, the largest pore density is located in the inner
hatch area.

Therefore, although the particles gradually deform and the degree of
oxidation increases, in the PBF-EB additive manufacturing of Ti6Al4V powder, with the
repeated use of the TC4 powder, the metal porosity does not change significantly.
Although the specific requirements for powder quality and porosity vary greatly
according to specific applications, medical and aerospace applications often
implement very strict regulations, but in fact, there are still not so many
documents on the quality of powder after repeated use, And generally believe
that it cannot be remelted and reused many times, sometimes it seems very
dogmatic, rather than based on proven facts.

As the additive manufacturing industry transitions to large-scale production,
the repeated use of additive manufacturing powders, especially the high
spherical powders required by the PBF process, will be one of the key factors in
reducing the overall cost of parts.
