China 3D Printing Aluminum Based Alloy Powder AlSi10Mg Powder 3D Printing Metal Powder

Overview of 3D printing metal powder AlSi10Mg

Powder characteristics: high powder sphericity, smooth surface, less satellite balls, low oxygen content, uniform particle size distribution, goodfluidity and high bulk density and tap density.

3D Printing Aluminum Base Alloy Powder AlSi10Mg Production Process

Step 1: High Quality Material

Step 2: Melting

Step 3: Atomized

Step 4: Filter

Step 5: Collect

Step 6: Dry

Step 7:Grading

Step 8: Inspection

Step 9:Packing

Applicable Process: Powder can be used in laser/electron beam additive manufacturing (SLM/EBM), powder metallurgy (PM), spray coating and other processes.

Applicable equipment: Powder can be used in various types of metal 3D printers, including Renishaw in the UK, EOS (EOSINT M series) in Germany, Concept Laser, 3D systems in the United States, laser melting equipment, and domestic research institutes and enterprises. Research and development of selected laser melting equipment, such as Huaying Hi-Tech, Platinum and so on.

Powder application: Aluminum-based metal powder is widely used in aerospace parts and automotive parts, profile surface spraying, powder metallurgy.

Product specifications: 0-45 μm, 0-53 μm, 15-45 μm, 15-53 μm, 45-105 μm. (All kinds of granular metal powder can be customized according to customer requirements)

The main application of 3D printing metal powder AlSi10Mg

Aerospace

Molds

Automotive

Medical instruments

Chemical composition(weight %)

Type	Si	Mn	Ni	Zn	Sn	Al	Cu	Ti	Fe
AlSi10Mg	9.0-11.0	≤0.45	≤0.05	≤0.1	≤0.05	Bal.	≤0.1	≤0.15	≤0.55

Powder oxygen and nitrogen content

Particle size	O/ppm	N/ppm
15-53μm	≤800	≤500
45-105μm	≤500	≤300





Company Profile

Tongrun Nano Technology Co. Ltd. (TRUNNANO) is a trusted global chemical material supplier & manufacturer with over 12-year-experience in providing super high-quality chemicals and nanomaterials, including boride powder, nitride powder, graphite powder, sulfide powder, 3D printing powder, etc.

The company has a professional technical department and Quality Supervision Department, a well-equipped laboratory, and equipped with advanced testing equipment and after-sales customer service center.If you are looking for high-quality AlSi10Mg Powder, please feel free to contact us or click on the needed products to send an inquiry.

Storage Condition of AlSi10Mg Powder

Damp reunion will affect AlSi10Mg Powder  dispersion performance and using effects, therefore, AlSi10Mg Powder should be sealed in vacuum packing and stored in cool and dry room, the AlSi10Mg Powder can not be exposure to air. In addition, the AlSi10Mg Powder should be avoided under stress.



Packing & Shipping of AlSi10Mg Powder

We have many different kinds of packing which depends on the AlSi10Mg Powder quantity.

AlSi10Mg Powder packing:vacuum packing, 100g, 500g or 1kg/bag, 25kg/barrel, or as your request.

AlSi10Mg Powder shipping:could be shipped out by sea , by air, by express, as soon as possible once payment receipt.

Payment Methods of AlSi10Mg Powder

L/C, T/T, Western Union, Paypal, Credit Card etc.
